Monday, August 8, 2011

LED Drive using TPS61042

This Chip from TI is simple to integrate into your designs and this solution is good for production of lighting gadgets, here a consistent quality and predictable performance is easily obtained.
TPS61042 30-V, 500-mA Switch Boost Converter in QFN-8 for White LED Applications
LED-driver application that drives four LEDs with 20 mA of forward current and operates from an input voltage range of 1.8 to 6.0 V.
The entire circuit consists of the control IC, two small ceramic caps, an inductor, a diode, and a current sense resistor. The primary power-supply functions and the secondary features such as load disconnect, overvoltage protection, and PWM dimming have been implemented with a control IC and five small surface-mount passive components. Read more - LED Drive TPS61042 at eem
LED-driver considerations - By Michael Day

Fluke Ti32 Thermal Imager for Industries

The new Fluke Ti32 combines a powerful 320x240 sensor into the award winning, rugged design of the Ti25 and Ti10, delivering the first industrial grade, high performance thermal imager.

Fluke Ti32 Thermal Imager for Industries

No need to carry pen and paper-record findings by speaking into the imager. Voice annotations can be recorded with every image you take. Decide for yourself, Amazing Fluke Instrument Test. Thermal imagers from fluke. Ti32 Infrared Camera survives a 2 meter drop - without a scratch.

Fluke Ti32 Thermal Imager for Industries

One-handed focus capability, emissivity correction, reflected background temperature compensation, and transmission correction increase the accuracy of measurements in most situations

Specifications -

Temperature measurement range (not calibrated below -10 °C) -20 °C to +600 °C (-4 °F to +1112 °F)

Detector type 320 X 240 Focal Plane Array, uncooled microbolometer

Thermal sensitivity (NETD) ≤ 0.045 degrees C and 45 mK

Infrared spectral band 7.5 μm to 14 μm (long wave)
